The economic threaded rod for standard applications.

Threaded rod G M

The G M threaded rod is a standard threaded rod for all basic applications without the dynamic or seismic performance categories. Due to the mechanical properties according to the EN ISO 898-1 the threaded rod is approved for the use with fischer injection systems. Various steel grades and galvanization grades enable a wide range of applications.

Variantet e produktit

Download of image data

Variantet e produktit

36 variante produktesh

Drill diameter

Min. effect. anchorage depth

Max. anchoring depth

Thread

Amount

GTIN (EAN-Code)

më shumë rrezultate

Gesehen 18 von 36 Variante(n)

Advantages

The large packaging unit with up to 50 pieces facilitates handling for series applications.
A wide selection of standard dimensions up to yard goods in various steel grades and galvanised types cover a wide range of applications.
The mechanical properties according to standard EN ISO 898-1 guarantee a safe application.
Variable anchorage depths allow efficient installation with fischer injection systems.

Applications

Steel structures
Railing
Staircases
Wood structures
Gates

Building materials

The threaded rods G M are suitable for the fischer injection mortars in different building materials.
The approved building materials can be found in the fischer injection mortar documents.

Detajet (materialet e ndërtimit, ngarkesat, etj.) të çdo miratimi të disponueshëm zbatohen. Dokumentet e mëtejshme mund të gjenden në Qendra e shkarkimit.

Drill diameter ( d₀ )	12 mm
Min. effect. anchorage depth ( h_ef )	60 mm
Max. anchoring depth	200 mm
Thread ( M )	M10
Amount	20 pcs
GTIN (EAN-Code)	4048962434972

Drill diameter ( d₀ )	10 mm
Min. effect. anchorage depth ( h_ef )	60 mm
Max. anchoring depth	98 mm
Thread ( M )	M8
Amount	50 pcs
GTIN (EAN-Code)	4048962434781

Drill diameter ( d₀ )	10 mm
Min. effect. anchorage depth ( h_ef )	60 mm
Max. anchoring depth	160 mm
Thread ( M )	M8
Amount	20 pcs
GTIN (EAN-Code)	4048962434668

Drill diameter ( d₀ )	10 mm
Min. effect. anchorage depth	—
Max. anchoring depth	—
Thread ( M )	M8
Amount	1 pcs
GTIN (EAN-Code)	4006209403211

Drill diameter ( d₀ )	10 mm
Min. effect. anchorage depth ( h_ef )	60 mm
Max. anchoring depth	160 mm
Thread ( M )	M8
Amount	20 pcs
GTIN (EAN-Code)	4048962434712
